1. Product Specifications

Product: Cold-room insulation panels
Total quantity: Approximately 40,000 m²
Panel length: 10 m
Thicknesses: 100 mm, 150 mm and 200 mm
Facings: Standard pre-painted steel sheets on both sides
Core density: Above 38

Suppliers may quote different core materials separately.

1. Please Quote Each Thickness Separately

100 mm / 150 mm / 200 mm

1. Quotation Requirements

Please quote each thickness per square metre and itemize:

• Material price: ___ per m²
• Transportation to Jeddah, Riyadh and Dammam: ___ per m²
• On-site installation: ___ per m²
• All-in total: ___ per m²

Please state whether the prices include VAT, accessories such as flashings, aluminium profiles, sealant and fasteners, and on-site unloading.

1. Additional Requirements

Please provide:

• Minimum order quantity (MOQ)
• Estimated production, transportation and installation lead times
• Core density and steel facing thickness
• Effective panel width and jointing method
• Fire rating
• Quotation currency and validity

Please provide a preliminary quotation as soon as possible so that we can proceed promptly with supplier screening.

 Contact
Phone: +966542885247
Email: jxskylar0725@gmail.com

Saudi Arabia Project | RFQ for 100 Fixed Electric Dock Levelers

We have a large-scale warehouse project in Saudi Arabia and need to purchase 100 complete fixed electric dock levelers.

1. Product Specifications
1) Product: Complete fixed electric hydraulic dock leveler (pit-mounted, not mobile)
2) Quantity: 100 units
3) Pit dimensions: Length 3 m x Width 2 m x Depth 0.6 m
4) Rated capacity: 6 tonnes / 8 tonnes (please quote separately)
5) Installation: Recessed fixed installation in a pit
6) Power supply: Three-phase 400 V / 60 Hz; single-phase 230 V / 60 Hz (if applicable)
7) Country of use: Saudi Arabia

2. Complete Equipment Requirements
Please provide complete, fully operational fixed electric dock levelers, including the platform, lip plate, hydraulic power system, motor, electrical control box and necessary safety devices. Separate components or mobile dock levelers are not accepted.

3. Quotation Requirements (Per Unit)
1) Product price: ___ / unit
2) Transportation to Saudi Arabia: ___ / unit
3) On-site installation and commissioning: ___ / unit
4) All-in total: ___ / unit

Please provide separate all-in unit prices for the 6-tonne and 8-tonne options, and specify whether customs clearance, taxes and pit-related civil works are included.

4. Additional Requirements
Please provide product pictures, technical specifications, production and delivery lead times, and installation lead times.

Important: The equipment must be suitable for Saudi Arabia's 60 Hz power supply.

Please provide preliminary quotations as soon as possible. We will select suppliers promptly. Thank you!

Contact phone: +966542885247
Email: jxskylar0725@gmail.com

Saudi Arabia Warehouse Project | Selective Pallet Racking RFQ | 120,000 Pallet Positions
沙特仓储项目｜横梁式托盘货架询价｜120,000 个托盘位

项目说明 / Project
The project covers Riyadh, Jeddah and Dammam, with multiple warehouses and a total requirement of approximately 120,000 pallet positions.
项目涉及利雅得、吉达、达曼三个城市，多个仓库，货架总需求约 120,000 个托盘位。

一、货架规格 / Racking specifications

1. Type: Selective Pallet Racking
   类型：横梁式托盘货架。
2. Quantity: 120,000 pallet positions (total across the three cities)
   数量：120,000 个托盘位，三城市合计。
3. Levels: 5 levels (1 ground level + 4 rack levels), approximately 1.8 m per level
   层数：5 层，地面 1 层＋货架 4 层，层高约 1.8 米。
4. Pallet dimensions: 1.0 m × 1.2 m
   托盘尺寸：1.0 米 × 1.2 米。
5. Load per pallet: 1,200 kg
   单托承重：1,200 公斤。
6. Warehouse clear height: 9–12 m
   仓库净高：9–12 米。

二、两种方案分别报价 / Quote both options separately
Option A: 3 pallets per bay per level
方案 A：每跨每层放置 3 个托盘。
Option B: 2 pallets per bay per level
方案 B：每跨每层放置 2 个托盘。

三、报价要求 / Quotation requirements
Please quote each option per pallet position and itemize:
请两种方案分别按照每个托盘位的单价报价，拆分：

1. Racking product price: ___ / pallet position
   货架产品单价：___ /托盘位。
2. Transportation: ___ / pallet position
   运输费用：___ /托盘位。
3. On-site installation: ___ / pallet position
   现场安装费用：___ /托盘位。
4. All-in total: ___ / pallet position
   全包总价：___ /托盘位。

Please quote transportation and installation separately for Riyadh, Jeddah and Dammam.
运输及安装费用请分别按利雅得、吉达、达曼三个目的地报价。

四、其他要求 / Additional requirements
Please provide estimated production, transportation and installation lead times; quotation currency, whether taxes are included, and quotation validity.
请提供预计生产、运输及安装周期，以及报价币种、是否含税和有效期。

Please provide preliminary quotations for both options as soon as possible so that we can proceed promptly with supplier screening.
请尽快提供两种方案的初步报价，便于我们尽快筛选供应商。

联系方式 / Contact
Phone: +966542885247
Email: jxskylar0725@gmail.com

Dear Team,

Thanks you for your attention.

This is to confirm the exact specifications for the replacement Tavrida Control Module we require.

We have identified the necessary details from our existing unit:

Full Part Number: M286B13BRY11J13U01L84

Specific ISM Type: ISM15 LD_3 (as listed on the unit's label)

To reiterate the core requirements, the module must have:

• USB Interface for configuration.
• Wide Auxiliary Supply Voltage: 85-265 VDC.
• Control via Dry Contact Inputs, provided by the ISM15 LD_3 module.

NOTE : Our team is not familiar with the above requirement and we need crystal clear details for the above item kindly let us know that if we fix the above item in our panel we should not face any  technical error and also we need circuit drawing for the above item, help us on this to proceed further

I have attached Our existing Model Picture above kindly refer to that and do the needful awaiting for your positive response from your end.

Dear Vendor

Please quote below item as mentioned and check related Terms and Condition and required certificates

Terms and Condition:

1. We need the mentioned quantities.
2. Please mention If there MOQ applicable.
3. Delivery = at SABIC Head office in Jubail
4. Estimated delivery timelines.

Please your confirmation to submit below certificate after delivery?

• Routine Test Report
• Type Test Report
• Fire Test Report
• Mechanical/Armored Test Report
• Certificate of Conformity (CoC)
• SASO Quality Mark / SABER Product Registration
• Materials Warranties
• Materials Datasheets
• Additionally, please indicate any applicable shipping costs.
